船用发电机组

Since the first Cummins marine diesel engine was launched in 1919, Cummins has been committed to the development and production of marine diesel engines. In 1925, the company put the first fully enclosed marine diesel engine on the market; In the 1970s, v903, v504 and 555 series marine diesel engines occupied the market position; In the 1980s, Cummins produced B and C series diesel engines; In 1993, the headquarters of marine engines moved to Charleston, a coastal city in South Carolina, the United States. Since then, the sales of marine engines have been continuously renovated; By 1998, the Dadong telegraph explorer, equipped with four Cummins diesel engines, had set a new record for global navigation.


model

power

Diesel engine model

displacement

Bore x stroke

(mm)

displacement (L)

size (L*W*H)(mm)

weight (kg)

(kw/kva)

Cummins

CCFJ30J

30/37

4BTA3.9-GM47

4.L

102/120

3.9

1500*750*1320

1100

CCFJ40J

40/50

4BTA3.9-GM47

4.L

102/120

3.9

1500*750*1320

1100

CCFJ50J

50/63

6BT5.9-GM83

6.L

102/120

5.9

1850*820*1350

1200

CCFJ64J

64/80

6BT5.9-GM83

6.L

102/120

5.9

1850*820*1350

1280

CCFJ70J

70/88

6BTA5.9-GM83

6.L

102/120

5.9

1850*820*1350

1280

CCFJ75J

75/94

6BTA5.9-GM83

6.L

102/120

5.9

1900*850*1400

1350

CCFJ80J

80/100

6BTA5.9-GM100

6.L

102/120

5.9

1900*850*1400

1350

CCFJ90J

90/113

6BTA5.9-GM100

6.L

102/120

5.9

1900*850*1400

1700

CCFJ90J

90/113

6BTAA5.9-GM115

6.L

102/120

5.9

1900*850*1400

1700

CCFJ100J

100/125

6BTAA5.9-GM115

6.L

102/120

5.9

1900*850*1400

1700

CCFJ100J

100/125

6CT8.3-GM115

6.L

114/135

8.3

2100*900*1500

1900

CCFJ120J

120/150

6CTA8.3-GM155

6.L

114/135

8.3

2100*900*1500

1900

CCFJ150J

150/188

NT855-DM

6.L

140/152

14

2860*1300*1850

2900

CCFJ150J

150/188

6LTAA8.9-GM200

6.L

114/145

8.9

2500*1200*1600

2200

CCFJ160J

160/200

6LTAA8.9-GM200

6.L

114/145

8.9

2500*1200*1600

2200

CCFJ170J

170/212

6LTAA8.9-GM200

6.L

114/145

8.9

2500*1200*1600

2200

CCFJ180J

180/225

N855-DM

6.L

140/152

14

2860*1300*1850

3100

CCFJ200J

200/250

N855-DM

6.L

140/152

14

2860*1300*1850

3100

CCFJ240J

240/300

N855-DM

6.L

140/152

14

2860*1300*1850

3180

CCFJ250J

250/313

N855-DM

6.L

140/152

14

2860*1300*1850

3180

CCFJ270J

270/338

N855-DM

6.L

140/152

14

2860*1300*1850

3250

CCFJ280J

280/350

N855-DM

6.L

140/152

14

2860*1300*1850

3250

CCFJ300J

300/375

K19-DM

6.L

159/159

19

3100*950*2080

3750

CCFJ320J

320/400

K19-DM

6.L

159/159

19

3150*1000*2150

3850

CCFJ350J

350/438

K19-DM

6.L

159/159

19

3150*1000*2150

3850

CCFJ400J

400/500

K19-DM

6.L

159/159

19

3150*1000*2150

3950

CCFJ480J

480/600

KT38-DM

12.V

159/159

38

4100*1650*2200

6200

CCFJ500J

500/625

K38-DM

12.V

159/159

38

4100*1650*2200

6200

CCFJ550J

550/688

K38-DM

12.V

159/159

38

4100*1650*2200

6300

CCFJ600J

600/750

K38-DM

12.V

159/159

38

4100*1650*2200

6300

CCFJ640J

640/800

K38-DM

12.V

159/159

38

4100*1650*2200

6300

CCFJ700J

700/875

K38-DM

12.V

159/159

38

4100*1650*2200

6300

CCFJ800J

800/1000

K38-DM

12.V

159/159

38

4200*1700*2350

7000

CCFJ850J

850/1062

K38-DM

12.V

159/159

38

4200*1700*2350

7000

CCFJ900J

900/1125

K50-DM

12.V

159/159

38

4400*2000*2400

9900

1. the above technical parameters are 50Hz, the rated voltage is 400/230v, the power factor is 0.8, and the wiring mode is 3-phase and 4-wire. 60Hz generator set can be customized according to the special needs of customers.


2. the generator can select Kaihua, Kaijieli, Stanford, lileisenma, marathon and other well-known brands according to the needs of customers.


3. this data sheet is for reference only and is subject to change without notice.


Installation diagram and reference dimensions


  model

model

Concrete foundation plan

(mm2)

Total area of machine room

(mm2)

Small height of machine room

(mm)

V-68GF

2500×1000

4400×3300

3000

V-80GF

2500×1000

2500×1000

3000

V-104GF

2700×1000

4600×3300

3000

V-120GF

2700×1000

4700×3300

3000

V-140GF

3000×1200

4900×3300

3000

V-160GF

3500×1200

5000×3300

3000

V-200GF

3500×1500

5000×3300

3000

V-260GF V-300GF V-320GF

4000×1500

6000×3300

3000

V-360GF V-400GF

4000×1500

6000×3300

3000


Reference dimension of domestic unit machine room



model

Small height of machine room

(mm)

remarks

Model of single 40-200kw6 cylinder engine room

5000×3600×3200

135系列

Two 40-200kw6 cylinder machine rooms

6000×5000×3500

135系列

Single 200-400kw12 cylinder machine room

6000×5000×3200

135系列

Two 200-400kw12 cylinder machine rooms

8000×6000×3500

135系列

Single (closed) 500-600kw machine room

10000×7000×5000

8V190

Single (closed) 500-600kw machine room

9000×7000×5000

8V190

Single (closed) 700-1000kw machine room

11000×8000×5500

12V190

Single (open) 700-1000kw machine room

9000×8000×5500

12V190


Notes for use of diesel generator set

1. 0\ ~ -30\; 15w-40cd grade engine oil is specified for engine oil (or according to the requirements of diesel engine instructions).


2. The starting temperature is above +5 ℃; With water oil temperature heating device, the starting temperature is -15 ℃; When the unit is used below 0 ℃, antifreeze and other low-temperature starting measures shall be adopted.


3. Unit noise coefficient: ≤ 85 ~ 95dB (a), in line with international standards.


4. In addition to providing 8kw-1600kw land-based units, the company can also provide marine units with the same power level and various 60Hz 1800 rpm generator units.


5. The generator units produced by the company comply with gb/t2820.1 5、. 6 and ISO8528 "reciprocating internal combustion engine driven generator set".


6. Voltage regulation mode: automatic or manual.


7. Attention of users in cold areas: according to the change of temperature, the engine oil, diesel oil and coolant should be properly adjusted to ensure the normal operation of the unit.


8. With the continuous updating of products, in case of any change or change of sample parameters, the accompanying documents shall prevail. The company has the final right of interpretation without further notice.
